An MDPE wall flange kit that makes external water outlets straightforward to fit from MDPE pipework. Designed for tradespeople, installers and builders, it offers a robust, compression-based connection with no need for specialist tools. Contents

• 1 x MDPE Wall Flange 20mm – ½" BSP (MDPEWF20-12BSPF)
• 1 x MDPE Elbow 25mm – ½" BSP (MDPEELB25-12BSPM)
• 1 x Lever Valve (BRVALVE12BSPM-F)

Key features

• MDPE PN10 fittings rated for up to 10 bar, suitable for a range of water supply and external outlet installations
• Compression connections provide a tight seal without soldering or specialist equipment
• Wall flange forms a stable outlet point on flat surfaces, with a ½" BSP threaded port for easy attachment
• Brass, nickel-plated lever valve delivers reliable on/off control with corrosion resistance for field use
• Not supplied: PTFE tape; it must be purchased separately for thread sealing

Usage and practical notes

Install the wall flange to a clean, flat surface using appropriate fixings. The included 20mm wall flange and 25mm elbow are both ½" BSP connections, enabling a straightforward threaded join to the external outlet or hose setup. Use standard MDPE compression fittings for the 20mm and 25mm run, ensuring all pipe ends are cut square and deburred.

Apply PTFE tape to threaded connections (not included) to achieve a leak-tight seal. After assembly, perform a pressure leak test at a comfortable test pressure to confirm integrity. Avoid over-tightening fittings to prevent damaging threads or pipework.

Ideal uses

Outdoor taps, irrigation feeds, and light industrial or commercial exterior water outlets where MDPE piping is already in use. This kit is well suited to tasks requiring a swift, durable external connection without bespoke components.
