This Wall Flange Kit gives tradespeople a ready-to-fit MDPE connection solution for 32mm piping. It combines a wall flange, a 32mm MDPE valve and Geka fittings—designed for reliable, leak-free connections in water supply, irrigation and light industrial piping.

Kit contents

• 1 x MDPE Wall Flange 32mm – ¾" BSP (MDPEWF32-34BSPF)
• 1 x MDPE Valve 32mm (MDPEVALVE32)
• 1 x Geka Type Fitting 13mm Barb (GK13MM)
• 1 x Geka Type Fitting ¾" BSP (GK34BSPM)

Key features and benefits

• MDPE fittings rated to PN10 (up to 10 bar / 145 psi), suitable for common domestic and light industrial pressures
• Wall flange compression fittings provide a secure connection to flat surfaces, helping neat, tidy installations
• MDPE valve enables flow control within the MDPE system without replacing components
• Geka connectors offer quick, tool-free assembly with high-integrity seals; brass bodies resist corrosion in harsh environments
• 13mm barb and ¾" BSP threads support versatile hose and pipe connections, simplifying assemblies and future maintenance
• Chemically resistant MDPE material helps minimise maintenance in outdoor and damp conditions

Use cases and installation notes

Ideal for water supply and irrigation mains, site retrofit projects, and systems where MDPE piping is specified. The kit’s compression fittings negate the need for specialised tooling, provided fittings are aligned and tightened per manufacturer guidance. Ensure pipes are cut cleanly, deburred and entered fully to achieve a leak-free seal. For best results, check that the 32mm MDPE pipe matches the 32mm valve and flange sizing, and that the Geka fittings are fully engaged for a watertight connection.
